Industries Belt Steamers Belt Steamers Model BS-600

Steamers for Breweries

Steam Italy's broad line of steaming equipment for the brewing industry.

Discover how breweries are sanitizing with steam: a modern and effective approach.

Steam sanitation is based on the use of high-temperature dry saturated steam, capable of removing dirt and eliminating microorganisms without the use of harsh chemicals. Steam cleaning is proving particularly effective against biofilms and residues that are difficult to remove with traditional methods. This approach delivers safe, effective, rapid and repeatable sanitation — a fundamental requirement for those working in the food sector and breweries.

Steam and Sanitation: Real Benefits for Breweries

Compared with traditional methods, steam offers tangible, measurable benefits for those running a brewery:

  • Microbicidal efficacy without chemical residues: High-temperature dry saturated steam effectively reduces microbial load, eliminating the risk of leaving residues that could contaminate the product or alter its organoleptic characteristics.
  • Dramatically reduced intervention times: Steam sanitation operations require significantly less time than traditional chemical protocols, reducing production downtime.
  • Greater safety for operators: Eliminating chemical detergents and sanitizers reduces the risk of exposure to harsh substances during cleaning operations.
  • Environmental sustainability: Steam uses only water, eliminating the disposal of chemical products and reducing the overall environmental impact of the production process.
  • Standardization and repeatability: Steam sanitation enables process standardization and allows intervention on complex components, such as pipework and fittings, that are difficult to reach with other systems.
Built to Last
Heavy-duty stainless steel construction for long service life.
Uniform Results
Engineered for even steam distribution and consistent quality.
Energy Efficient
Optimized steam utilization reduces operating costs.
Easy to Maintain
Accessible design for quick cleaning and minimal downtime.
Custom Solutions
Available in a wide range of sizes and configurations.

Specifications

Model BS-600
Belt Width 600 mm (23.6 in)
Belt Length Custom (Standard up to 46 ft)
Steam Pressure 15–60 PSI
Heating Type Direct Steam
Temperature Range 180°F – 250°F (82°C – 121°C)
Belt Speed 0.5 – 10 ft/min (adjustable)
Construction Stainless Steel (304/316)
Power Requirements 220/460V, 3 Phase, 60 Hz
Options Insulation, Multiple Zones, CIP System, Product Infeed/Outfeed Conveyors

Specifications are subject to change. Contact NECE for current requirements.

Key Applications

  • Vegetables
  • Seafood
  • Meats & Poultry
  • Pasta & Grains
  • Prepared Foods

Standard Features

  • Stainless steel construction
  • Direct steam injection system
  • Adjustable belt speed
  • Steam trap system
  • Insulated panels
  • Access doors for easy cleaning

Options & Accessories

  • Multiple heating zones
  • Automatic belt tracking
  • CIP (Clean-in-Place) system
  • Product infeed & outfeed conveyors
  • Condensate recovery system

Ready to Find the Right

NECE delivers the cleaning power, reliability, and support you need with the right equipment for the job and the service to keep you working.
